System And Components
299-5205 WIRING GP-PANEL -110-VACS/N TFM267-UP
Group No: 299-5205
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6Y6815 | 1 GASKET AS (CONNECTOR) | 1 | |
| 2468370 | 2 GROMMET | 1 | |
| 3626644 | 3 CIRCUIT BREAKER AS (25-AMPERE)(ALTERNATOR) | 1 | |
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 1 | |
| 2867243 | 4 FILM-INSTRUCTION (HOLD FREQUENCY, READ OMM) | 1 | |
| 3773835 | 5 HARNESS AS-SWITCH | 1 | |
| 3009957 | 6 HARNESS AS-SWITCH (GOVERNOR CONTROL) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 5P2321 | TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW) | 2 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 3010070 | 7 RECEPTACLE | 2 | |
| 3010072 | 8 ENCLOSURE GP-ELECTRICAL | 1 | |
| 3802611 | COVER | 1 | |
| 3802612 | LATCH | 1 | |
| 3802613 | SEAL | 1 | |
| 3010073 | 9 BRACKET | 1 | |
| 3010074 | 10 PLATE | 1 | |
| 3B4501 | 12 LOCKWASHER | 4 | |
| 4D1836 | 13 SWITCH-TOGGLE (HOLD FREQUENCY) | 1 | |
| 5C2874 | 14 NUT (M5X0.8-THD) | 4 | |
| 5C8312 | 15 NUT (M4X0.7-THD) | 4 | |
| 7I2273 | 16 BOLT (M5X0.8X16-MM) | 4 | |
| 6V5210 | 17 SCREW-MACHINE (M4X0.7X10-MM) | 4 | |
| 7K1181 | 18 STRAP-CABLE | 2 | |
| 7X7729 | 19 WASHER (11X25X3-MM THK) | 4 | |
| 8P8540 | 20 GROMMET | 1 | |
| 8T0328 | 21 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 4 | |
| 9G4191 | 23 GROMMET | 1 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 |
