System And Components
299-5206 WIRING GP-POWER RECEPTACLE -220-VACS/N TFM1-266
Group No: 299-5206
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6Y6815 | 1 GASKET AS (CONNECTOR) | 1 | |
| 2468370 | 2 GROMMET | 1 | |
| 2545092 | 3 CIRCUIT BREAKER AS (25-AMPERE)(ALTERNATOR) | 1 | |
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 1 | |
| 2602915 | 4 RECEPTACLE AS-CONNECTOR | 2 | |
| 2867243 | 5 FILM-INSTRUCTION (HOLD FREQUENCY, READ OMM) | 1 | |
| 2995202 | 6 CABLE AS | 1 | |
| 3009957 | 7 HARNESS AS-SWITCH (GOVERNOR CONTROL) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 5P2321 | TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW) | 2 | |
| 1809339 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 3010072 | 8 ENCLOSURE GP-ELECTRICAL | 1 | |
| 3010073 | 9 BRACKET | 1 | |
| 3010074 | 10 PLATE | 1 | |
| 3B4501 | 11 LOCKWASHER | 4 | |
| 4D1836 | 12 SWITCH-TOGGLE (HOLD FREQUENCY) | 1 | |
| 5C2874 | 13 NUT (M5X0.8-THD) | 4 | |
| 5C8312 | 14 NUT (M4X0.7-THD) | 4 | |
| 6V4298 | 15 BOLT (M5X0.8X16-MM) | 4 | |
| 6V5210 | 16 SCREW-MACHINE (M4X0.7X10-MM) | 4 | |
| 7K1181 | 17 STRAP-CABLE | 4 | |
| 7X7729 | 18 WASHER (11X25X3-MM THK) | 4 | |
| 8P8540 | 19 GROMMET | 1 | |
| 8T0328 | 20 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 4 | |
| 9G4191 | 22 GROMMET | 1 |
