System And Components
288-2631 WIRING GP-SCREED -ELECTRIC HEATS/N TFM1-266
Group No: 288-2631
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7R7941 | 1 CLAMP | 6 | |
| 3083026 | 2 HARNESS AS-SCREED | 1 | |
| 4D7388 | 3 CLIP | 3 | |
| 7K1181 | 4 STRAP-CABLE | 5 | |
| 2545092 | 5 CIRCUIT BREAKER AS (25-AMPERE)(SCREED HEAT) | 4 | |
| 2L8069 | TERMINAL-RING (2-GA TO 10-GA, 3/8-IN SCREW) | 1 | |
| 7R7951 | 7 PLATE | 3 | |
| 7X2535 | 8 BOLT (M6X1X60-MM) | 4 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 10 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 11 BOLT (M10X1.5X20-MM) | 5 | |
| 4D7794 | 12 CLIP | 1 | |
| 2972669 | 13 PLATE | 1 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5C2890 | 15 NUT (M6X1-THD) | 2 | |
| 8T6974 | 16 BOLT (M6X1X80-MM) | 2 |
