Assembly
100%

351-0903 WIRING GP-SCREEDS/N TFM1-UP

Group No: 351-0903
Part NumberPart NameQty
3S20931 STRAP-CABLE70
6I14182 SPACER (8.2X12.7X28.7-MM THK)4
7R79513 PLATE1
7V56284 PLATE (TOP)3
8T96555 MOUNT-ISOLATION8
14396446 PLATE-RETAINER3
16312017 HORN AS (24-VOLT, LOW TONE)1
20339778 LEVER2
23651499 WASHER-NYLON (11.17X19.05X1.6MM THK)2
276461510 COVER1
304568711 CONTROL GP-UNPROGRAMMED (ACCUGRADE)1
327612512 LAMP GP-SIGNAL (24-VOLT, RH)1
327851513 LAMP GP-SIGNAL (24-VOLT, LH)1
350594314 SUPPORT AS1
352065715 BOX GP-CONTROL (RH)1
352065816 BOX GP-CONTROL (LH)1
352065917 BOX GP-CONTROL (SCREED)1
352066818 HARNESS AS-SCREED (PAVER TO SCREED)1
356549119 COVER AS1
356600820 BRACKET AS1
356786121 PLATE AS2
362663622 HARNESS AS-CONTROL (SCREED)2
362663723 HARNESS AS-SCREED (EXTENDER, LH)1
362663824 HARNESS AS-SCREED (EXTENDER, RH)1
362663925 HARNESS AS-SCREED (MAIN)1
362840826 MOUNT AS2
362841127 BRACKET AS2
367195328 BRACKET2
061884429 GROMMET1
096616630 WASHER-HARD (4.5X9X1-MM THK)10
099364931 BOLT (M8X1.25X40-MM)4
139042832 CLAMP2
1G995933 CLAMP6
206151134 CLAMP-HALF2
208007535 CLAMP-HALF2
352396836 CLIP (LADDER)1
352396937 CLIP (LADDER)2
4B486338 WASHER (4.7X11X1.2-MM THK)8
5C831239 NUT (M4X0.7-THD)8
5P411640 WASHER-HARD (8.8X20.5X2-MM THK)14
6V797841 SCREW-MACHINE (10-32X0.375-IN)4
6V949142 SCREW-MACHINE (M4X0.7X20-MM)12
6V967243 SCREW-MACHINE (M4X0.7X16-MM)2
7K118144 STRAP-CABLE49
7R794145 CLAMP2
7X253446 BOLT (M6X1X50-MM)4
7X253547 BOLT (M6X1X60-MM)2
7X772948 WASHER (11X25X3-MM THK)14
8C845149 BOLT (M6X1X40-MM)2
8T412150 WASHER-HARD (11X21X2.5-MM THK)6
8T413351 NUT (M10X1.5-THD)6
8T413652 BOLT (M10X1.5X25-MM)4
8T413753 BOLT (M10X1.5X20-MM)6
8T413954 BOLT (M12X1.75X30-MM)4
8T417955 BOLT (M12X1.75X20-MM)2
8T418956 BOLT (M8X1.25X20-MM)6
8T419157 BOLT (M10X1.5X16-MM)1
8T419558 BOLT (M10X1.5X30-MM)6
8T422359 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422460 WASHER-HARD (8.8X16X2-MM THK)4
8T490861 BOLT (M8X1.25X25-MM)4
8T754762 BOLT (M8X1.25X30-MM)4
9X248063 BOLT (M6X1X45-MM)6
