System And Components
328-9591 WIRING GP-SCREED HEATER -750-MM EXTENSIONS/N TFM1-UP
Group No: 328-9591
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2937187 | 1 WIRING GP-SCREED HEATER (750-MM EXTENSION, LH) | 1 | |
| 2937258 | 2 WIRING GP-SCREED HEATER (750-MM EXTENSION, RH) | 1 | |
| 3044670 | 3 HARNESS AS-BOX (RH)(RH) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 9X0141 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 9X1343 | RECEPTACLE AS-CONNECTOR (40-PIN) | 2 | |
| 9G3695 | PLUG-SEAL | 28 | |
| 0966166 | WASHER-HARD (4.5X9X1-MM THK) | 3 | |
| 1073786 | BOLT (M4X0.7X12-MM) | 3 | |
| 1261766 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 24 | |
| 1441636 | PIN-CONNECTOR (14-GA TO 18-GA) | 28 | |
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 3044671 | 4 HARNESS AS-BOX (LH)(LH) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 9X0141 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 9X1343 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 8T3998 | BOLT (M4X0.7X12-MM) | 3 | |
| 9G3695 | PLUG-SEAL | 24 | |
| 0966166 | WASHER-HARD (4.5X9X1-MM THK) | 3 | |
| 1261766 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 26 | |
| 1441636 | PIN-CONNECTOR (14-GA TO 18-GA) | 30 | |
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 1313540 | 5 LOCKNUT (M8X1.25-THD) | 4 | |
| 2997249 | 6 BRACKET | 2 | |
| 6V3918 | 7 BOLT (M8X1.25X50-MM) | 4 | |
| 7K1181 | 8 STRAP-CABLE | 22 | |
| 8T4224 | 9 WASHER-HARD (8.8X16X2-MM THK) | 8 |
