System And Components
391-0179 WIRING GP-SCREED HEATERS/N TFM1-UP
Group No: 391-0179
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D1326 | 1 LOCKWASHER | 8 | |
| 7R7951 | 2 PLATE | 2 | |
| 7V5628 | 3 PLATE (TOP) | 6 | |
| 4V0612 | 4 PLATE | 4 | |
| 1772215 | 5 STRAP-DUAL CLAMP | 4 | |
| 4820689 | 6 HARNESS AS-WIRING (MAIN, RH) | 1 | |
| 4820690 | 7 HARNESS AS-WIRING (MAIN, LH) | 1 | |
| 4820687 | 8 HARNESS AS-WIRING (EXTENSION, RH) | 1 | |
| 4820688 | 9 HARNESS AS-WIRING (EXTENSION, LH) | 1 | |
| 3968608 | 10 PANEL GP-CONTROL | 1 | |
| 2293128 | PANEL AS | 1 | |
| 4796687 | 11 COVER AS | 1 | |
| 1102023 | STUD-WELD (M10X1.5X25-MM) | 1 | |
| 3903431 | 12 WIRE AS | 1 | |
| 4796185 | 13 BOX GP-SCREED CONTROL | 1 | |
| 1305300 | 14 CLIP | 6 | |
| 1546583 | 15 CLAMP-HALF | 8 | |
| 1G9959 | 16 CLAMP | 12 | |
| 3H2900 | 17 GROMMET | 1 | |
| 5P4115 | 18 WASHER-HARD (7.2X19X2-MM THK) | 3 | |
| 7K1181 | 19 STRAP-CABLE | 25 | |
| 7R7941 | 20 CLAMP | 4 | |
| 7X2535 | 21 BOLT (M6X1X60-MM) | 2 | |
| 7X7729 | 22 WASHER (11X25X3-MM THK) | 2 | |
| 8C8451 | 23 BOLT (M6X1X40-MM) | 4 | |
| 8T3844 | 24 BOLT (M6X1X70-MM) | 2 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 26 NUT (M10X1.5-THD) | 4 | |
| 8T4137 | 27 BOLT (M10X1.5X20-MM) | 5 | |
| 8T4138 | 28 BOLT (M6X1X20-MM) | 3 | |
| 8T4191 | 29 BOLT (M10X1.5X16-MM) | 1 | |
| 8T6912 | 30 BOLT (M8X1.25X50-MM) | 4 | |
| 9X2045 | 31 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 9X2480 | 32 BOLT (M6X1X45-MM) | 8 | |
| 1602251 | 33 SLEEVE-ABRASION (39.4-IN EACH) | ||
| 7P1695 | 34 WASHER (10.5X19X3-MM THK) | 13 | |
| 9X8256 | 35 WASHER (6.6X12X2-MM THK) | 4 | |
| 2042281 | 36 STRAP-CABLE | 4 | |
| 8T4136 | 37 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4182 | 38 BOLT (M10X1.5X45-MM) | 2 | |
| 5P7211 | 39 SEAL (0.5-M) |
