372-0710 WIRING GP-WINDOW WIPERS/N TFM1-UP

Group No: 372-0710

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	40
1107885	2 KNOB AS-WIPER SWITCH	2
0140816	SETSCREW (8-32X0.5-IN)	1
1126174	3 SWITCH GP-ROTARY (WIPER, WASHER)	2
2H3920	LOCKWASHER	1
6V8369	NUT (7/16-28-THD)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	6
8T8737	PLUG-SEAL	2
1028806	KIT-RECEPTACLE (8-PIN)	1
1772215	4 STRAP-DUAL CLAMP	1
3633958	5 HARNESS AS-WINDOW WIPER (CANOPY)	1
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	2
1552265	KIT-CONNECTING PLUG (8-PIN)	2
1552274	KIT-CONNECTING PLUG (6-PIN)	2
8T8737	PLUG-SEAL	10
1028802	KIT-RECEPTACLE (2-PIN)	1
1809340	SOCKET-CONNECTOR (14-GA TO 18-GA)	18
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM)
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM)
3633960	6 CHANNEL AS	1
3720713	7 HARNESS AS-WINDOW WIPER (JUMPER)	1
1552270	KIT-CONNECTING PLUG (2-PIN)	1
1809340	SOCKET-CONNECTOR (14-GA TO 18-GA)	2
2L8075	TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW)	1
2L8081	TERMINAL-RING (14-GA TO 16-GA, 1/2-IN SCREW)	1
4P7429	8 CLIP (LADDER)	1
5C9553	9 BOLT (M6X1X16-MM)	4
6P0699	10 GROMMET	1
7K1181	11 STRAP-CABLE	11
8T4205	12 WASHER-HARD (7.2X14.5X2-MM THK)	4
