System And Components
269-2817 CONSOLE GP-OPERATORS/N TFM259-UP
Group No: 269-2817
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1111777 | 1 BUMPER-RUBBER | 4 | |
| 1602226 | 2 BALL BEARING | 1 | |
| 2692914 | 3 BALL BEARING | 4 | |
| 2715094 | 4 CONSOLE AS | 1 | |
| 2764641 | 5 PIN AS | 1 | |
| 2770734 | 6 COVER | 1 | |
| 2844484 | 7 KIT-ADJUSTER | 1 | |
| 2863769 | 8 SPACER (10.5X30X47-MM THK) | 2 | |
| 2863770 | 9 PLATE AS | 1 | |
| 2863771 | 10 RAIL AS | 1 | |
| 2863772 | 11 SHIM (1-MM THK) | 4 | |
| 2863776 | 12 HANDLE | 1 | |
| 2877588 | 13 SWIVEL GP | 1 | |
| 2920958 | 14 HINGE AS | 2 | |
| 2920959 | 15 SPACER | 2 | |
| 2920960 | 16 COVER AS | 1 | |
| 3704144 | 17 PLATE AS (LH) | 1 | |
| 3704148 | 18 PLATE AS (RH) | 1 | |
| 1053481 | 19 BOLT-SOCKET HEAD (M8X1.25X20-MM) | 8 | |
| 1419203 | 20 SCREW-BUTTON HEAD (M10X1.5X30-MM) | 6 | |
| 5C2874 | 21 NUT (M5X0.8-THD) | 8 | |
| 5C7261 | 22 NUT (M8X1.25-THD) | 8 | |
| 5P4116 | 23 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7X7729 | 24 WASHER (11X25X3-MM THK) | 18 | |
| 7Y7388 | 25 SCREW-BUTTON HEAD (M5X0.8X12-MM) | 4 | |
| 7Y7389 | 26 SCREW (M5X0.8X16-MM) | 4 | |
| 7Y7394 | 27 SCREW-BUTTON HEAD (M8X1.25X25-MM) | 2 | |
| 8T0328 | 28 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4133 | 30 NUT (M10X1.5-THD) | 9 | |
| 8T4137 | 31 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4182 | 32 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4189 | 33 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4196 | 34 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4198 | 35 BOLT (M10X1.5X100-MM) | 2 | |
| 8T4224 | 36 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 9X1046 | 37 SCREW (M4X0.7X18-MM) | 2 | |
| 1455664 | 38 SEAL (142-CM) |
