311-6189 CONSOLE GP-OPERATORS/N TFM281-UP

Group No: 311-6189

Part Number	Part Name	Qty
4174688	1 PANEL GP-INSTRUMENT	1
3116188	2 HARNESS AS-CONSOLE	1
1552255	KIT-CONNECTING PLUG (12-PIN)	2
1552256	KIT-CONNECTING PLUG (12-PIN)	2
1552265	KIT-CONNECTING PLUG (8-PIN)	1
1907614	KIT-RECEPTACLE (12-PIN)	2
1028801	KIT-RECEPTACLE (12-PIN)	2
1028806	KIT-RECEPTACLE (8-PIN)	1
1809339	PIN-CONNECTOR (14-GA TO 18-GA)	56
1809340	SOCKET-CONNECTOR (14-GA TO 18-GA)	56
1107887	3 SWITCH AS-START (KEY)	1
7T6799	NUT-MOUNTING (1-32-THD)	1
1028804	KIT-RECEPTACLE (4-PIN)	1
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	4
1787539	4 RECEPTACLE AS (POWER SUPPLY)	1
2848905	5 CONTROL GP-UNPRGMED MONITOR (ADVISOR)	1
3045687	6 CONTROL GP-UNPROGRAMMED (OPERATOR CONSOLE)	1
7K1181	7 STRAP-CABLE	10
4P7429	8 CLIP (LADDER)	1
2823067	9 PLATE	4
1305300	10 CLIP	11
8T4205	11 WASHER-HARD (7.2X14.5X2-MM THK)	19
8T4171	12 BOLT (M6X1X12-MM)	4
1286157	13 PLATE	1
1414976	14 SCREW-WASHER HEAD (4-40X0.5-IN)	4
8T9655	15 MOUNT-ISOLATION	8
8T9658	16 SPACER (8.2X12.7X25.4-MM THK)	4
5P4116	17 WASHER-HARD (8.8X20.5X2-MM THK)	7
5C7261	18 NUT (M8X1.25-THD)	13
8C6354	19 CAP-RECEPTACLE (ET CONNECTOR)	1
1G9090	20 S-HOOK	1
3E6328	21 ALARM GP (24-VOLT)	1
3111746	22 CLAMP	2
2796446	23 CLIP	1
5A3604	24 BOLT-SOCKET HEAD (M8X1.25X25-MM)	4
8T4224	25 WASHER-HARD (8.8X16X2-MM THK)	11
8T0338	26 BOLT-SOCKET HEAD (M8X1.25X45-MM)	2
8T4200	27 BOLT (M8X1.25X16-MM)	2
4P8134	28 CLIP (LADDER)	1
9X1046	30 SCREW (M4X0.7X18-MM)	10
8T4223	31 WASHER-HARD (13.5X25.5X3-MM THK)	1
8T4244	32 NUT (M12X1.75-THD)	1
5C2890	34 NUT (M6X1-THD)	6
8T4138	35 BOLT (M6X1X20-MM)	6
2502297	36 METER GP-SERVICE (WHITE BACKLIGHT)	1
3105922	37 PLATE	1
3080503	38 SPACER	1
1272170	39 SCREW-TRUSS HEAD (M8X1.25X20-MM)	4
1080358	40 FLASHER AS (24-VOLT)(TURN SIGNAL, HAZARD)	1
1G9089	41 CHAIN (1-DM)
4B4863	42 WASHER (4.7X11X1.2-MM THK)	10
6V3507	43 SEAL-RECTANGULAR	1
3520244	44 WASHER-HARD (8.8X20.5X2-MM THK)	4
0323237	45 SPACER (10.93X19.05X25.4-MM THK)	1
6V3918	46 BOLT (M8X1.25X50-MM)	1
