System And Components
295-2143 COVER GP-ACCESSS/N TFM1-UP
Group No: 295-2143
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3109816 | 1 PLATE GP-SCREED (RH) | 1 | |
| 3109817 | 2 PLATE GP-SCREED (LH) | 1 | |
| 3109821 | 3 BUSHING | 8 | |
| 3109829 | 4 HANDLE AS (LEVER) | 8 | |
| 2422804 | HANDLE | 1 | |
| 3153713 | LEVER | 1 | |
| 3109831 | 5 CLAMP | 8 | |
| 3125044 | 6 PLATE AS | 4 | |
| 3153692 | 7 PLATE AS (LH) | 2 | |
| 3153693 | 8 PLATE AS (RH) | 2 | |
| 0950922 | 9 RING-RETAINING | 8 | |
| 7X7729 | 10 WASHER (11X25X3-MM THK) | 32 | |
| 8T0389 | 11 LOCKNUT (M10X1.5-THD) | 20 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4195 | 14 BOLT (M10X1.5X30-MM) | 16 | |
| 8T7547 | 15 BOLT (M8X1.25X30-MM) | 16 |
