System And Components
263-6007 COVER GP-ENGINE & PLATFORMS/N TFM283-UP
Group No: 263-6007
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1C3750 | 1 LATCH | 2 | |
| 5P7957 | 2 LANYARD | 1 | |
| 5P7958 | 3 SLEEVE-CABLE SPLICE | 1 | |
| 6V7636 | 4 PIN AS-SPRING | 3 | |
| 8T2444 | 5 STUD-BALL | 2 | |
| 1087756 | 6 ROD | 3 | |
| 1111777 | 7 BUMPER-RUBBER | 4 | |
| 1228427 | 8 SPACER (9X14X3.5-MM THK) | 2 | |
| 1425057 | 9 SHIM (2-MM THK) | 2 | |
| 1641342 | 10 BOLT-SPECIAL (M10X1.5X28-MM) | 2 | |
| 1746944 | 11 BOLT-SPECIAL | 2 | |
| 2942382 | 12 LATCH AS | 4 | |
| 1939297 | 13 PLATE (BENT) | 1 | |
| 3366672 | 14 HANDLE AS (PULL) | 1 | |
| 2084729 | 15 HINGE | 2 | |
| 2086190 | 16 PLATE | 2 | |
| 2182207 | 17 LATCH AS-DOOR (ROTARY) | 1 | |
| 2208262 | 18 ROD | 1 | |
| 3053159 | 19 PAWL | 3 | |
| 2393152 | 20 HINGE | 2 | |
| 2393169 | 21 PLATE | 2 | |
| 2393173 | 22 HINGE | 1 | |
| 1300599 | 23 PLATE | 4 | |
| 2431146 | 24 HINGE | 1 | |
| 2720002 | 25 STRIKER AS | 1 | |
| 2751130 | 26 COVER AS | 1 | |
| 2751131 | 27 PLATE | 1 | |
| 2751133 | 28 PLATE | 1 | |
| 2751134 | 29 COVER AS | 1 | |
| 3701939 | 30 COVER | 1 | |
| 2751138 | 31 COVER AS | 1 | |
| 2751141 | 32 PLATE | 1 | |
| 2751143 | 33 PLATE | 1 | |
| 3547754 | 34 PANEL AS (LH) | 1 | |
| 3718089 | 35 PANEL AS (RH) | 1 | |
| 2768850 | 36 PLATE | 2 | |
| 2768948 | 37 DOOR AS-ACCESS | 1 | |
| 2768950 | 38 SHIM (3.5-MM THK) | 1 | |
| 2768996 | 39 LATCH | 1 | |
| 2769063 | 40 SHIM (5-MM THK) | 1 | |
| 2774780 | 41 PLATE | 1 | |
| 3066519 | 42 PLATE | 1 | |
| 2838406 | 43 PLATE AS (RH) | 1 | |
| 4162255 | 44 PLATE AS (LH) | 1 | |
| 5D9629 | ROD | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 7 | |
| 1305300 | CLIP | 1 | |
| 7T1099 | LINK | ||
| 2869954 | 45 PLATE AS | 2 | |
| 3100806 | 46 PLATE | 2 | |
| 2869956 | 47 PLATE | 1 | |
| 2869957 | 48 PLATE | 1 | |
| 2869958 | 49 ROD | 1 | |
| 2885945 | 50 HINGE | 1 | |
| 3663079 | 51 SPRING-GAS (DOOR ACCESS) | 1 | |
| 3053169 | 52 PAWL | 1 | |
| 3240787 | 53 PLATE | 1 | |
| 1419203 | 54 SCREW-BUTTON HEAD (M10X1.5X30-MM) | 18 | |
| 3B4617 | 55 PIN-COTTER | 3 | |
| 8T9366 | 56 SCREW-SOCKET FLAT HEAD | 3 | |
| 5C2874 | 57 NUT (M5X0.8-THD) | 8 | |
| 5C2890 | 58 NUT (M6X1-THD) | 1 | |
| 5C7261 | 59 NUT (M8X1.25-THD) | 13 | |
| 5C9553 | 60 BOLT (M6X1X16-MM) | 5 | |
| 5C9853 | 61 SCREW (M8X1.25-THD) | 2 | |
| 5P1076 | 62 WASHER-HARD (13.5X30X4-MM THK) | 3 | |
| 5P4116 | 63 WASHER-HARD (8.8X20.5X2-MM THK) | 21 | |
| 6V4298 | 64 BOLT (M5X0.8X16-MM) | 8 | |
| 6V8185 | 65 NUT (1/4-20-THD) | 1 | |
| 7X7729 | 66 WASHER (11X25X3-MM THK) | 80 | |
| 7Y7394 | 67 SCREW-BUTTON HEAD (M8X1.25X25-MM) | 22 | |
| 8C8585 | 68 SCREW-BUTTON HEAD (M10X1.5X20-MM) | 27 | |
| 8T0328 | 69 WASHER-HARD (5.5X10X1-MM THK) | 16 | |
| 8T4121 | 70 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 71 NUT (M10X1.5-THD) | 65 | |
| 8T4136 | 72 BOLT (M10X1.5X25-MM) | 9 | |
| 8T4138 | 74 BOLT (M6X1X20-MM) | 4 | |
| 8T4189 | 75 BOLT (M8X1.25X20-MM) | 9 | |
| 8T4195 | 76 BOLT (M10X1.5X30-MM) | 19 | |
| 8T4196 | 77 BOLT (M10X1.5X35-MM) | 5 | |
| 8T4199 | 78 BOLT (M8X1.25X12-MM) | 3 | |
| 8T4183 | 79 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4205 | 80 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4223 | 81 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4224 | 82 WASHER-HARD (8.8X16X2-MM THK) | 15 | |
| 8T4244 | 83 NUT (M12X1.75-THD) | 3 | |
| 8T4908 | 84 BOLT (M8X1.25X25-MM) | 5 | |
| 9X8256 | 85 WASHER (6.6X12X2-MM THK) | 4 | |
| 5P7211 | 86 SEAL (0.1-M EACH) | ||
| 5P7211 | 86A SEAL (0.9-M EACH) | ||
| 1984777 | 87 WASHER-HARD (11X25X10-MM THK) | 12 | |
| 4F8711 | 88 PLUG-BUTTON | 1 | |
| 8T3991 | 89 SCREW-BUTTON HEAD (M6X1X20-MM) | 2 |
