System And Components
328-9585 COVER GP-SCREEDS/N TFM1-UP
Group No: 328-9585
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P8837 | 1 LOCK PIN | 4 | |
| 2603418 | 2 BALL JOINT (LH) | 4 | |
| 2765629 | 3 PIN | 4 | |
| 2870280 | 4 SUPPORT AS | 2 | |
| 3109821 | 5 BUSHING | 4 | |
| 3109829 | 6 HANDLE AS | 4 | |
| 3153713 | LEVER | 1 | |
| 3109831 | 7 CLAMP | 4 | |
| 3289582 | 8 COVER AS | 2 | |
| 1348273 | SCREW-FLAT HEAD (M10X1.5X25-MM) | 4 | |
| 3289584 | 9 GATE AS | 2 | |
| 3289630 | 10 ROD AS | 2 | |
| 8T3573 | NUT (M20X1.5-THD) | 1 | |
| 0950922 | 11 RING-RETAINING | 4 | |
| 1156433 | 12 WASHER (11X50X6-MM THK) | 8 | |
| 2519567 | 13 NUT (M20X1.5-THD) | 4 | |
| 8T0389 | 14 LOCKNUT (M10X1.5-THD) | 8 | |
| 8T4122 | 15 WASHER-HARD (17X32X3.5-MM THK) | 10 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 10 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T7547 | 18 BOLT (M8X1.25X30-MM) | 8 |
