Assembly
100%

350-5927 COVER GP-SCREEDS/N TFM1-UP

Group No: 350-5927
Part NumberPart NameQty
13871251 BUMPER1
22916412 WASHER (9X35X5-MM THK)4
31098203 PLATE2
35642044 COVER AS2
35703205 SUPPORT AS (LH)1
35703216 SUPPORT AS (RH)1
36999507 COVER1
36999518 COVER1
37866209 COVER GP (LH)1
380279110 COVER GP (RH)1
383366411 COVER-RUBBER2
383366512 PLATE2
383978013 BRACKET1
8T419714 BOLT (M8X1.25X40-MM)2
131354015 LOCKNUT (M8X1.25-THD)2
5C726116 NUT (M8X1.25-THD)7
5P411617 WASHER-HARD (8.8X20.5X2-MM THK)17
7X772918 WASHER (11X25X3-MM THK)42
8T413319 NUT (M10X1.5-THD)6
8T413720 BOLT (M10X1.5X20-MM)16
8T418921 BOLT (M8X1.25X20-MM)8
8T419522 BOLT (M10X1.5X30-MM)20
8T422423 WASHER-HARD (8.8X16X2-MM THK)8
8T490824 BOLT (M8X1.25X25-MM)12
7X787725 STRIP-EDGE (62-CM)
