287-0269 PLATE GP-SCREEDS/N TFM1-UP

Group No: 287-0269

Part Number	Part Name	Qty
2293138	1 SENSOR GP-TEMPERATURE (SCREED HEAT)	4
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	2
9X1813	SLEEVE (57-CM)
1028802	KIT-RECEPTACLE (2-PIN)	1
2459690	2 PLATE	4
2459693	3 STUD (M12X1.75X100-MM)	48
2489997	4 NUT-BRASS (M12X1.75-THD)	160
2490604	5 NUT-BRASS (M14X2-THD)	16
2490923	6 STUD (M14X2X116-MM)	8
2493037	7 WASHER-SPRING	32
2724935	8 CLAMP	8
2765733	9 STUD (M12X1.75X58-MM)	32
2870266	10 PLATE	32
2870267	11 PLATE-SCREED (SLIDING, LH)	1
2870268	12 PLATE-SCREED (SLIDING, RH)	1
2913693	14 COVER AS	4
3153688	15 SUPPORT AS	4
3153689	16 SUPPORT AS	4
2952106	17 PLATE AS-SCREED (MAIN, RH)	1
2952107	18 PLATE AS-SCREED (MAIN, LH)	1
2997224	19 COVER AS	4
2997225	20 COVER	4
4552249	21 HEATER AS (240-VOLT, 700-WATT)	2
3501489	22 HEATER AS-SCREED (240-VOLT, 650-WATT)	2
3501490	23 HEATER AS-SCREED (240-VOLT, 720-WATT)	2
3501491	24 HEATER AS-SCREED (240-VOLT, 2600-WATT)	2
3501492	25 HEATER AS-SCREED (240-VOLT, 2900-WATT)	2
1297164	RECEPTACLE AS-CONNECTOR (1-PIN)	2
7X0515	26 WASHER-HARD (17X35X5-MM THK)	32
7X7729	27 WASHER (11X25X3-MM THK)	32
8T4136	29 BOLT (M10X1.5X25-MM)	32
8T4138	31 BOLT (M6X1X20-MM)	16
8T4223	32 WASHER-HARD (13.5X25.5X3-MM THK)	80
8T4224	33 WASHER-HARD (8.8X16X2-MM THK)	8
9X8256	34 WASHER (6.6X12X2-MM THK)	16
