System And Components
282-8520 SENSOR GP-SONICS/N TFM1-UP
Group No: 282-8520
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1082408 | 1 SENSOR GP-GRADE (CONTROL) | 1 | |
| 1131550 | KIT-TRANSDUCER | 1 | |
| 1131551 | KIT-FILTER (FOAM) | 1 | |
| 2853251 | PLATE-RETAINER | 1 | |
| 1082410 | 2 BAIL-TEMPERATURE | 1 | |
| 1082423 | 3 CABLE AS | 1 | |
| 1113262 | NUT (6-32-THD) | 2 | |
| 1113263 | NUT (8-32-THD) | 2 | |
| 1118205 | BACKSHELL | 1 | |
| 1046863 | CLAMP | 1 | |
| 1104295 | PLUG | 1 | |
| 1104296 | PLUG | 1 | |
| 1106863 | CABLE | 1 | |
| 1111308 | BUSHING | 2 | |
| 1349621 | 4 HANDLE | 3 | |
| 1349622 | 5 BRACKET | 1 | |
| 1469410 | 6 COLLAR | 2 | |
| 2980644 | 7 MOUNT AS-SENSOR | 2 | |
| 2643631 | 8 BOLT (3/4-10X2.5-IN) | 1 | |
| 7X0366 | 9 BOLT (3/4-10X2-IN) | 2 | |
| 8C8842 | 10 BOLT (3/4-10X4-IN) | 1 | |
| 8T4994 | 11 WASHER-HARD (20X36.5X3.5-MM THK) | 1 |
