System And Components
323-5667 EXHAUST GP-FLEXIBLES/N A5D1-UP; B5P1-UP
Group No: 323-5667
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I4039 | 1 GASKET | 1 | |
| 1374499 | 2 CLAMP AS | 1 | |
| 2998903 | 3 CLAMP | 2 | |
| 3025547 | 4 SHEET | 1 | |
| 3235589 | 5 TUBE | 1 | |
| 3298997 | 6 BRACKET AS | 1 | |
| 3298999 | 7 TUBE | 1 | |
| 3299000 | 8 TUBE AS | 1 | |
| 3343220 | 9 PIPE AS-EXHAUST | 1 | |
| 3347861 | 10 INSULATION | 1 | |
| 3478955 | 11 INSULATION | 1 | |
| 3478956 | 12 INSULATION | 1 | |
| 3478957 | 13 INSULATION | 1 | |
| 3002865 | 14 MUFFLER | 1 | |
| 3003670 | 15 CLAMP AS | 4 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 18 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 3 | |
| 8T4189 | 20 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 4 |
