System And Components
333-4785 TURBOCHARGER GPS/N C4E1-UP
Group No: 333-4785
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0563 | 2 NUT (M10X1.5-THD) | 7 | |
| 6I0593 | 3 BOLT (M10X1.5X30-MM) | 2 | |
| 6I0654 | 4 BOLT (M10X1.5X25-MM) | 3 | |
| 6I0817 | 5 ADAPTER | 1 | |
| 6I4200 | 6 BOLT (M10X1.5X16-MM) | 3 | |
| 9Y9381 | 7 WASHER-HARD | 1 | |
| 1068916 | 9 BOLT (M6X1X16-MM) | 2 | |
| 3617519 | 11 ROD-THREADED | 7 | |
| 1945390 | 12 GASKET-MANIFOLD | 1 | |
| 2258530 | 13 GASKET | 1 | |
| 3533477 | 14 GASKET-TURBOCHARGER | 1 | |
| 3533478 | 15 GASKET-TURBOCHARGER | 1 | |
| 2274562 | 16 ELBOW-EXHAUST | 1 | |
| 5075019 | 17 LINE AS-OIL | 1 | |
| 2693086 | 17A CLAMP-BAND | 2 | |
| 2780310 | 18 SOLENOID AS (WASTEGATE) | 1 | |
| 2780361 | 19 BOLT (M10X1.5X45-MM) | 8 | |
| 2984570 | 20 GASKET-EXHAUST MANIFOLD | 1 | |
| 2984576 | 21 CLIP | 1 | |
| 3018255 | 22 TUBE AS | 1 | |
| 2258524 | 22A BOLT-SPECIAL (M10X1.5X23-MM) | 2 | |
| 2258526 | 22B WASHER (10.4X13.75X1.37-MM THK) | 4 | |
| 3018256 | 23 MANIFOLD-EXHAUST | 1 | |
| 3020581 | 24 ADAPTER-EXHAUST | 1 | |
| 3032116 | 25 CLIP | 4 | |
| 3776869 | 26 BRACKET | 1 | |
| 3072805 | 27 BRACKET | 1 | |
| 3117458 | 28 TUBE AS | 1 | |
| 0328047 | 28A FERRULE | 1 | |
| 0328191 | 28B NUT | 1 | |
| 2984576 | 28C CLIP | 2 | |
| 3006520 | 28D HOSE AS | 1 | |
| 1072348 | 28E CLIP | 2 | |
| 3160525 | 29 TURBOCHARGER GP | 1 | |
| 3264508 | 30 TUBE AS | 1 | |
| 0328047 | 30A FERRULE | 2 | |
| 0328191 | 30B NUT | 1 | |
| 0358014 | 30C NUT | 1 |
