System And Components
322-3056 HOUSING GP-FRONTS/N C4Z1-UP
Group No: 322-3056
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 6 | |
| 6I0454 | 2 BOLT (M10X1.5X70-MM) | 3 | |
| 6I0645 | 3 BOLT (M8X1.25X25-MM) | 4 | |
| 3443434 | 4 BOLT | 1 | |
| 0676179 | 5 DOWEL | 1 | |
| 1003751 | 6 BOLT (M8X1.25X65-MM) | 5 | |
| 1004830 | 7 BOLT (M10X1.5X20-MM) | 1 | |
| 1013895 | 8 BOLT (M8X1.25X35-MM) | 2 | |
| 1243815 | 9 BOLT (M8X1.25X16-MM) | 9 | |
| 3683158 | 10 WASHER | 1 | |
| 2268767 | 11 COVER AS-FRONT | 1 | |
| 2268766 | 11A GASKET-COVER | 1 | |
| 2323666 | 12 WASHER-THRUST | 1 | |
| 2433253 | 13 HOUSING-FRONT | 1 | |
| 3403610 | 14 GEAR-CAMSHAFT (68-TEETH) | 1 | |
| 2773012 | 15 GASKET-COVER | 1 | |
| 2880422 | 16 SEAL-CRANKSHAFT | 1 | |
| 2916517 | 17 PLATE | 1 | |
| 3599431 | 18 GEAR-IDLER (73-TEETH) | 1 |
