System And Components
383-9669 EXHAUST GPS/N TEN1-UP
Group No: 383-9669
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5E9892 | 1 PIN | 1 | |
| 1355049 | 2 CABLE AS | 1 | |
| 5P7958 | SLEEVE-CABLE SPLICE | 1 | |
| 3015155 | 3 TUBE | 1 | |
| 3521930 | 4 SUPPORT AS | 1 | |
| 1599541 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3593495 | 5 MUFFLER AS | 1 | |
| 3736522 | 6 SUPPORT | 1 | |
| 3940842 | 7 STACK GP-PAVER VENTILATION | 1 | |
| 1076125 | HINGE AS | 1 | |
| 2323121 | NUT (M10X1.25-THD) | 1 | |
| 4167009 | 8 COVER | 1 | |
| 5C2890 | 9 NUT (M6X1-THD) | 1 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 7X7729 | 11 WASHER (11X25X3-MM THK) | 10 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 13 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4189 | 14 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4195 | 15 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4908 | 16 BOLT (M8X1.25X25-MM) | 2 | |
| 8T6974 | 17 BOLT (M6X1X80-MM) | 1 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 2 |
