System And Components
381-0734 CONSOLE GP-OPERATORS/N TEN1-UP
Group No: 381-0734
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1111777 | 1 BUMPER-RUBBER | 3 | |
| 1122096 | 2 SCREW-HEX SOCKET (M5X0.8X30-MM) | 4 | |
| 2423072 | 3 WASHER (8.5X25X3-MM THK) | 4 | |
| 3098924 | 4 ADAPTER AS | 1 | |
| 3109985 | 5 STEERING WHEEL AS | 1 | |
| 3391670 | 6 LEVER GP | 1 | |
| 3856527 | 7 CHAIN GP | 1 | |
| 3906051 | LINK | 23 | |
| 3906052 | TERMINAL | 1 | |
| 4214494 | 8 SPACER | 1 | |
| 4730157 | 9 COVER | 1 | |
| 4730158 | 10 COVER | 2 | |
| 4730159 | 11 PLATE | 1 | |
| 4730160 | 12 COVER GP-CONSOLE | 1 | |
| 4730164 | 13 COVER AS | 1 | |
| 5C2874 | NUT (M5X0.8-THD) | 4 | |
| 4732640 | 14 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 0859865 | NUT | 18 | |
| 1140489 | 15 BOLT (M5X0.8X75-MM) | 8 | |
| 1554098 | 16 SCREW-BUTTON HEAD (M3X0.5X1-MM) | 8 | |
| 2412481 | 17 COVER | 1 | |
| 2659709 | 18 SCREW-FLAT HEAD (M5X0.8X10-MM) | 4 | |
| 3C6969 | 19 NUT (M3X0.5-THD) | 4 | |
| 4B4274 | 20 WASHER (5.5X13X1.2-MM THK) | 12 | |
| 6V4248 | 21 BOLT (M10X1.5X25-MM) | 4 | |
| 6V9498 | 22 WASHER-HARD (3.2X7X0.5-MM THK) | 4 | |
| 7P1695 | 23 WASHER (10.5X19X3-MM THK) | 4 | |
| 8T0289 | 24 BOLT (M5X0.8X20-MM) | 4 | |
| 8T0325 | 25 BOLT (M5X0.8X14-MM) | 6 | |
| 8T3016 | 26 WASHER (5.3X10X1-MM THK) | 6 | |
| 8T4908 | 27 BOLT (M8X1.25X25-MM) | 4 |
