System And Components
Assembly
100%

499-6330 ARM GP-DROPPART OF 417-6650 SCREED AR

Group No: 499-6330
Part NumberPart NameQty
24181201 NUT (M20X1.5-THD, LH)2
26034172 BALL JOINT (RH)2
26034183 BALL JOINT (LH)2
30847954 TURNBUCKLE (M20X1.5X75-MM)2
30848035 PLATE-INDICATOR2
43216296 PLATE-INDICATOR2
49963287 BUSHING2
49963298 BOLT (M16X2X110-MM)2
50057429 ARM AS (RH)1
500574310 ARM AS (LH)1
068640511 WASHER (26X63.5X6-MM THK)4
268321212 BOLT (M14X2X70-MM)4
171933213 BOLT (M24X2X70-MM)4
176531114 LOCKNUT (M16X2-THD)2
251956715 NUT (M20X1.5-THD)2
3E433716 RIVET-POP4
8T039017 NUT-SELF LOCKING (M24X2-THD)4
8T412318 WASHER (22X35X3.5-MM THK)2
8T497019 BOLT (M6X1X14-MM)4
9X825620 WASHER (6.6X12X2-MM THK)4
9X825721 WASHER (17.5X30X3.5-MM THK)12
