Assembly
100%

417-6620 FRAME GP-SCREEDPART OF 417-6650 SCREED AR

Group No: 417-6620
Part NumberPart NameQty
26034171 BALL JOINT (RH)2
42325712 FRAME AS-FRONT (LH)1
42325723 FRAME AS-FRONT (RH)1
42325734 FRAME AS (SLIDING, RH)1
42325765 FRAME AS (SLIDING, LH)1
42325986 TUBE AS2
43140617 FRAME AS-REAR (RH)1
43156318 FRAME AS-REAR (LH)1
43251019 BUSHING4
1T058010 RING-RETAINING4
432510311 SHAFT2
449040312 SHIM (0.2-MM THK)2
449040813 SHIM (0.2-MM THK)2
432510214 BUSHING4
251956715 NUT (M20X1.5-THD)2
2D152316 RING-RETAINING4
8T414017 BOLT (M16X2X60-MM)16
8T419418 BOLT (M12X1.75X50-MM)8
8T422319 WASHER-HARD (13.5X25.5X3-MM THK)8
9X825720 WASHER (17.5X30X3.5-MM THK)16
