System And Components
417-6641 PLATE & HEATER GP-SCREEDPART OF 417-6650 SCREED AR
Group No: 417-6641
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2293138 | 1 SENSOR GP-TEMPERATURE (SCREED HEAT) | 4 | |
| 9X1813 | SLEEVE (57-CM) | ||
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 4390078 | 2 PLATE-SENSOR | 4 | |
| 2489997 | 3 NUT-BRASS (M12X1.75-THD) | 72 | |
| 4314058 | 4 PLATE AS-SCREED (EXTENDER, LH) | 1 | |
| 4194909 | STUD (M12X1.75X100-MM) | 8 | |
| 4314064 | PLATE-SCREED (EXTENDER, LH) | 1 | |
| 4314060 | 5 PLATE AS-SCREED (EXTENDER, RH) | 1 | |
| 4194909 | STUD (M12X1.75X100-MM) | 8 | |
| 4330170 | PLATE-SCREED (EXTENDER, RH) | 1 | |
| 4316937 | 6 PLATE AS-SCREED (MAIN) | 1 | |
| 4194909 | STUD (M12X1.75X100-MM) | 20 | |
| 4314063 | PLATE-SCREED (MAIN) | 1 | |
| 4325119 | 7 PLATE-CLAMP | 4 | |
| 4361049 | 8 COVER-SENSOR | 4 | |
| 5C7261 | 9 NUT (M8X1.25-THD) | 12 | |
| 5C9553 | 10 BOLT (M6X1X16-MM) | 8 | |
| 5P4116 | 11 WASHER-HARD (8.8X20.5X2-MM THK) | 20 | |
| 6V2316 | 12 BOLT (M8X1.25X12-MM) | 8 | |
| 8T6870 | 13 BOLT (M8X1.25X70-MM) | 12 | |
| 9X8256 | 14 WASHER (6.6X12X2-MM THK) | 8 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 36 |
