356-9096 LINES GP-CYLINDER -WITH BLADES/N DJE1-UP
Group No: 356-9096
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931295 | 1 CLAMP | 2 | |
| 1391762 | 2 HOSE AS | 2 | |
| 1391765 | 3 HOSE AS | 2 | |
| 1797874 | 4 TUBE AS | 1 | |
| 1797875 | 5 TUBE AS | 1 | |
| 1850506 | 6 VALVE GP-CONTROL (BLADE, MEDIUM PRESSURE) | 1 | |
| 4842312 | 7 HOSE AS | 1 | |
| 3569197 | 8 SUPPORT | 1 | |
| 1875812 | 9 HOSE AS | 1 | |
| 1488341 | 10 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1503037 | 11 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T2530 | ELBOW | 1 | |
| 1504048 | 12 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8722 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 7J9108 | 13 SEAL-O-RING | 8 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4194 | 16 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T7547 | 19 BOLT (M8X1.25X30-MM) | 3 | |
| 7K1181 | 20 STRAP-CABLE | 1 | |
| 1488342 | 21 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 |
