System And Components
356-9093 LINES GP-FRONT -MEDIUM PRESSURES/N DJE1-UP
Group No: 356-9093
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931295 | 1 CLAMP | 1 | |
| 1087581 | 2 HOSE AS | 1 | |
| 1907727 | 3 VALVE GP-CONTROL (MEDIUM PRESSURE, WITH RELIEF) | 1 | |
| 2895547 | 4 PLATE | 1 | |
| 3259054 | 5 HOSE AS | 2 | |
| 3569193 | 6 TUBE AS | 1 | |
| 3569197 | 7 SUPPORT | 1 | |
| 3569221 | 8 HOSE AS | 1 | |
| 3661084 | 9 TUBE AS | 1 | |
| 1488346 | 10 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 1488364 | 11 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 6V8398 | 12 SEAL-O-RING | 4 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4136 | 14 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4184 | 15 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4196 | 16 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T7547 | 19 BOLT (M8X1.25X30-MM) | 3 |
