System And Components
478-3974 CONTROL GP-STEERINGS/N NED1-115; NRG1-137; NTT1-117
Group No: 478-3974 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X0818 | 1 BOLT (M8X1.25X45-MM) | 2 | |
| 7R5382 | 2 SPRING | 1 | |
| 8T4224 | 3 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 8T4994 | 4 WASHER-HARD (20X36.5X3.5-MM THK) | 1 | |
| 8X1147 | 5 SPACER (10.3X15.9X74.7-MM THK) | 3 | |
| 0817511 | 6 RING | 3 | |
| 1698332 | 7 BLOCK AS-MOUNTING | 1 | |
| 2380251 | 8 SCREW-BUTTON HEAD (M10X1.5X25-MM) | 4 | |
| 2412489 | 9 CAP (COVER) | 1 | |
| 2503949 | 10 SPACER | 1 | |
| 3086353 | 11 ARM AS | 1 | |
| 3109985 | 12 STEERING WHEEL AS | 1 | |
| 3493567 | 13 PLATE | 1 | |
| 3734327 | 14 SENSOR GP-POSITION (STEERING) | 1 | |
| 4592887 | 15 STEERING COLUMN GP | 1 | |
| 4830925 | 16 HUB | 1 | |
| 4831006 | 17 PLATE | 1 | |
| 0951265 | 18 SETSCREW-SOCKET | 1 | |
| 0962633 | 19 KEY-SQUARE | 1 | |
| 1128728 | 20 SCREW (10-32X1.25-IN) | 2 | |
| 1313983 | 21 BOLT-SOCKET HEAD (M8X1.25X35-MM) | 2 | |
| 1T0550 | 22 PIN-SPRING | 2 | |
| 2108375 | 23 SPACER (10.5X16X13-MM THK) | 4 | |
| 4M5281 | 24 BOLT (1/4-20X0.75-IN) | 2 | |
| 6V0894 | 25 SEAL-O-RING | 1 | |
| 6V8227 | 26 NUT (M18X1.5-THD) | 1 | |
| 8T0277 | 27 PIN-SPRING | 1 | |
| 8T4177 | 28 BOLT (M8X1.25X90-MM) | 3 |
