473-6222 WIRING GP-ENGINEPART OF 472-7901 INSTALLATION AR-ENGINE

Group No: 473-6222
Part NumberPart NameQty
7K11811 STRAP-CABLE12
8T87992 BOOT (RED)1
48573453 HARNESS AS-ENGINE1
09936494 BOLT (M8X1.25X40-MM)1
13053005 CLIP2
13257896 CLIP (LADDER)2
13369347 SPACER (11X20X25-MM THK)3
17722158 STRAP-DUAL CLAMP2
32703259 STRAP-CABLE2
344567410 NUT (M8X1.25-THD)1
3T085211 LOCKNUT (M8X1.25-THD)1
4P758112 CLIP (LADDER)1
8F724213 WASHER (8.7X15.9X1.6-MM THK)1
8T364714 BOLT (M8X1.25X80-MM)1
8T418915 BOLT (M8X1.25X20-MM)1
8T422416 WASHER-HARD (8.8X16X2-MM THK)5
8T754717 BOLT (M8X1.25X30-MM)1
