System And Components
444-5382 CONSOLE GP-OPERATORPART OF 444-5403 ELECTRICAL AR
Group No: 444-5382
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2584648 | 1 SEAL (1-CM) | ||
| 3S2093 | 2 STRAP-CABLE | 2 | |
| 5P8500 | 3 KEY | 2 | |
| 7K1181 | 4 STRAP-CABLE | 4 | |
| 4678535 | 5 SWITCH AS-START (KEY) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1286157 | 6 PLATE | 1 | |
| 1809900 | 7 CAP AS | 2 | |
| 5P7958 | SLEEVE-CABLE SPLICE | 1 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 1799392 | LANYARD | 1 | |
| 2321792 | 8 HORN (24-VOLT TO 12-VOLT) | 1 | |
| 3083527 | 9 SWITCH AS-TOGGLE (OPERATOR LADDER UP, DOWN) | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 3447618 | 10 COVER-SEAL | 1 | |
| 3983073 | 11 CABLE AS | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(3-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 3314222 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 4419360 | 12 GUARD GP-VANDALISM | 1 | |
| 4639951 | 13 HARNESS AS-CONSOLE | 1 | |
| 4646803 | 14 CONTROL GP-ELECTRONIC | 1 | |
| 4705692 | 15 PANEL GP-INSTRUMENT | 1 | |
| 4866518 | 16 RESISTOR AS (FRONT) | 1 | |
| 4866518 | 16A RESISTOR AS (REAR) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1053486 | 17 BOLT-SOCKET HEAD (M6X1X50-MM) | 4 | |
| 1305300 | 18 CLIP | 6 | |
| 1336934 | 19 SPACER (11X20X25-MM THK) | 2 | |
| 1414976 | 20 SCREW-WASHER HEAD (4-40X0.5-IN) | 4 | |
| 1772215 | 21 STRAP-DUAL CLAMP | 1 | |
| 2039007 | 22 NUT (1-1/2-18-THD) | 1 | |
| 2098296 | 23 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 6 | |
| 3445673 | 24 NUT (M6X1-THD) | 1 | |
| 3445674 | 25 NUT (M8X1.25-THD) | 1 | |
| 3812621 | 26 MOUNTING-CABLE TIE | 1 | |
| 6V9671 | 27 SCREW-MACHINE (M3X0.5X12-MM) | 4 | |
| 8T3991 | 28 SCREW-BUTTON HEAD (M6X1X20-MM) | 1 | |
| 8T4224 | 29 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 8T6912 | 30 BOLT (M8X1.25X50-MM) | 2 | |
| 8T7547 | 31 BOLT (M8X1.25X30-MM) | 1 | |
| 9X8256 | 32 WASHER (6.6X12X2-MM THK) | 6 |
