478-3968 CONSOLE GP-OPERATORPART OF 444-5406 OPERATOR AR

Group No: 478-3968
Part NumberPart NameQty
8T41821 BOLT (M10X1.5X45-MM)2
28637692 SPACER (10.5X30X47-MM THK)2
8T41983 BOLT (M10X1.5X100-MM)2
7X77294 WASHER (11X25X3-MM THK)4
8T03285 WASHER-HARD (5.5X10X1-MM THK)26
8T03896 LOCKNUT (M10X1.5-THD)8
8T41217 WASHER-HARD (11X21X2.5-MM THK)16
8T42248 WASHER-HARD (8.8X16X2-MM THK)17
09659699 BOLT-SOCKET HEAD (M5X0.8X25-MM)13
096616610 WASHER-HARD (4.5X9X1-MM THK)16
134137411 BOLT-SOCKET HEAD (M5X0.8X20-MM)2
214173312 BOLT-SOCKET HEAD (M5X0.8X80-MM)4
221370013 BOLT-SOCKET HEAD (M4X0.7X16-MM)8
269291414 BALL BEARING4
539894015 PIN AS2
344567416 NUT (M8X1.25-THD)4
344567517 NUT (M10X1.5-THD)2
450947418 SCREW-BUTTON HEAD (M10X1.5X40-MM)8
454289619 SUPPORT AS1
8T3490NUT-WELD (M10X1.5-THD)4
8T3612NUT-WELD (M8X1.25-THD)4
454581820 RAIL AS1
455991521 BEARING2
455991622 PLATE2
455991823 COVER1
459288824 TERMINAL AS1
4629537TERMINAL1
4629538LINK20
459289125 SUPPORT1
539910926 COVER-DASH1
473622927 SPACER4
483092028 SUPPORT AS1
8T3612NUT-WELD (M8X1.25-THD)5
483092129 SUPPORT AS1
7T1099LINK3
8T3612NUT-WELD (M8X1.25-THD)6
8T8874NUT-WELD (M5X0.8-THD)4
1305300CLIP2
483092230 COVER-DASH (LEFT)1
483092331 COVER-DASH (RIGHT)1
483092432 COVER-DASH (FRONT)1
483793333 SHIM (2-MM THK)4
153800434 BOLT-SOCKET HEAD (M4X0.7X35-MM)8
5C287436 NUT (M5X0.8-THD)15
9X261637 SCREW-SOCKET (M8X1.25X16-MM)13
