System And Components
470-5692 PANEL GP-INSTRUMENTPART OF 444-5382 CONSOLE GP-OPERATOR
Group No: 470-5692
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4503368 | 1 COVER-PANEL (LOWER) | 1 | |
| 4503373 | 2 HARNESS AS-CONSOLE | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 2 | |
| 1944254 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 4177789 | 3 HARNESS AS-CONSOLE | 1 | |
| 4177002 | 4 MODULE GP-KEYPAD | 1 | |
| 2088469 | 5 LOCKNUT (M6X1-THD) | 14 | |
| 3999069 | 6 SWITCH AS-ROTARY (ENCODER ADAPTER) | 4 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 4346547 | 7 KIT-KNOB | 4 | |
| 4177007 | 8 MODULE GP-KEYPAD | 1 | |
| 4503367 | 9 COVER-PANEL (UPPER) | 1 | |
| 4177008 | 10 MODULE GP-KEYPAD | 1 | |
| 8C6365 | 11 BOLT-SOCKET HEAD (M3X0.5X6-MM) | 1 | |
| 0965962 | 12 WASHER-HARD (3.4X7X0.8-MM THK) | 17 | |
| 9B1117 | 13 LOCKWASHER | 9 | |
| 3679470 | 14 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 3950256 | 15 SWITCH AS-HORN | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 4177006 | 16 MODULE GP-KEYPAD | 1 | |
| 4177001 | 17 LEVER AS | 1 | |
| 1668637 | 18 SCREW-SOCKET HEAD (M4X0.7X12-MM) | 4 | |
| 3747465 | 19 CAP-SEAL | 2 | |
| 4503369 | 20 BRACKET AS | 1 | |
| 6V5683 | 21 BOLT (M6X1X16-MM) | 34 | |
| 3B4504 | 22 LOCKWASHER | 40 | |
| 4Y4667 | 23 WASHER (6.4X12.5X1.6-MM THK) | 40 | |
| 8T0267 | 24 BOLT-SOCKET HEAD (M6X1X12-MM) | 6 | |
| 4503370 | 25 PLATE-COVER | 1 | |
| 4503371 | 26 PLATE | 2 | |
| 2030099 | 27 BOLT-SOCKET HEAD (M3X0.5-THD) | 8 | |
| 3C6969 | 28 NUT (M3X0.5-THD) | 8 | |
| 4224542 | 29 BRACKET | 1 | |
| 4184657 | 30 COVER | 1 |
