System And Components
585-9425 PANEL GP-INSTRUMENTPART OF 444-5382 CONSOLE GP-OPERATOR
Group No: 585-9425
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5404957 | 1 HARNESS AS-CONSOLE | 1 | |
| 3950256 | 2 SWITCH AS-HORN | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1809339 | PIN-CONNECTOR (14-GA TO 18-GA) | 2 | |
| 3679470 | 3 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 5850150 | 4 LEVER AS | 1 | |
| 4690972 | BOOT | 1 | |
| 4690974 | CAP | 1 | |
| 4503373 | 5 HARNESS AS-CONSOLE (LIMP HOME) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 2 | |
| 1944254 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 4503369 | 6 BRACKET AS | 1 | |
| 4224542 | 7 BRACKET | 1 | |
| 4503370 | 8 PLATE-COVER | 1 | |
| 4503371 | 9 PLATE | 2 | |
| 4346547 | 10 KIT-KNOB | 4 | |
| 4177008 | 11 MODULE GP-KEYPAD (TOP, RH) | 1 | |
| 4177007 | 12 MODULE GP-KEYPAD (TOP, LH) | 1 | |
| 4177002 | 13 MODULE GP-KEYPAD (BOTTOM, LH) | 1 | |
| 4177006 | 14 MODULE GP-KEYPAD (WHEEL) | 1 | |
| 3999069 | 15 SWITCH AS-ROTARY (ENCODER ADAPTER) | 4 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 5425234 | 16 HOUSING AS | 1 | |
| 4503367 | 17 COVER-PANEL (UPPER) | 1 | |
| 4184657 | 18 COVER | 1 | |
| 3C6969 | 19 NUT (M3X0.5-THD) | 8 | |
| 9X8902 | 20 BOLT-SOCKET HEAD (M3X0.5X8-MM) | 1 | |
| 2030099 | 21 BOLT-SOCKET HEAD (M3X0.5-THD) | 8 | |
| 6V5683 | 22 BOLT (M6X1X16-MM) | 40 | |
| 8T0337 | 23 SCREW-MACHINE (M4X0.7X12-MM) | 4 | |
| 0965962 | 24 WASHER-HARD (3.4X7X0.8-MM THK) | 17 | |
| 9B1117 | 25 LOCKWASHER | 9 | |
| 4Y4667 | 26 WASHER (6.4X12.5X1.6-MM THK) | 40 | |
| 3B4504 | 27 LOCKWASHER | 40 | |
| 2088469 | 28 LOCKNUT (M6X1-THD) | 14 |
