Assembly
100%

462-2771 GUARD GP-CONVEYORPART OF 444-5405 CONVEYOR AR-DRAG & AUGER

Group No: 462-2771
Part NumberPart NameQty
49514861 PLATE-CONVEYOR4
45593712 GUARD AS (CONVEYOR)1
45679213 GUARD AS (LH)1
5M7937DOWEL2
8T3597NUT-WELD (M12X1.75-THD)2
45679254 GUARD AS (RH)1
5M7937DOWEL2
8T3597NUT-WELD (M12X1.75-THD)2
46244405 SUPPORT AS2
46337446 SUPPORT AS1
8T03897 LOCKNUT (M10X1.5-THD)4
7X77298 WASHER (11X25X3-MM THK)12
8T41839 BOLT (M12X1.75X40-MM)8
8T419510 BOLT (M10X1.5X30-MM)8
8T422311 WASHER-HARD (13.5X25.5X3-MM THK)12
8T495612 BOLT (M12X1.75X35-MM)4
495984213 SHIM (0.5-MM THK)8
