449-0386 CONVERSION GP-ROADINGAN ATTACHMENT

Group No: 449-0386

Part Number	Part Name	Qty
3S2093	1 STRAP-CABLE	5
7K1181	2 STRAP-CABLE	5
2560042	3 LAMP GP-REGISTRATION PLATE (12-VOLT)	1
2583849	4 PLATE-IDENTIFICATION (ENGLISH, GERMAN, ITALIAN)	1
2767695	5 MOUNTING GP-LIGHTING	1
2778422	6 PLATE-INFORMATION (NO. 15)	1
2957794	7 LIGHTING GP-WARNING BEACON (12-VOLT)	1
9W3326	LAMP (12-VOLT, 21-WATT)(MINIATURE)	1
2958345	8 MIRROR	1
3131647	9 BRACKET AS	1
3131648	10 SUPPORT AS	1
3180253	11 PLATE	1
4538831	12 PLATE	2
4853923	13 PLATE AS	2
8T3490	NUT-WELD (M10X1.5-THD)	1
5526921	14 SUPPORT-REAR	2
4934126	15 HARNESS AS-CONTROL	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	2
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	2
1552270	KIT-CONNECTING PLUG (2-PIN)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
1945226	TERMINAL AS (16-GA)	2
1945227	TERMINAL AS (14-GA)	2
4951475	16 PLATE	1
1293178	18 LOCKNUT (M6X1-THD)	2
1305300	19 CLIP	2
1313539	20 SCREW-FLAT HEAD (M8X1.25X30-MM)	2
3293356	21 NUT (M12X1.75-THD)	5
3445674	22 NUT (M8X1.25-THD)	2
5C9553	23 BOLT (M6X1X16-MM)	2
5P4116	24 WASHER-HARD (8.8X20.5X2-MM THK)	2
6V7357	25 BOLT (M6X1X25-MM)	2
6V9673	26 SCREW-MACHINE (M5X0.8X12-MM)	2
7X2535	27 BOLT (M6X1X60-MM)	4
8T4121	28 WASHER-HARD (11X21X2.5-MM THK)	4
8T4139	29 BOLT (M12X1.75X30-MM)	4
8T4179	30 BOLT (M12X1.75X20-MM)	4
8T4183	31 BOLT (M12X1.75X40-MM)	1
8T4191	32 BOLT (M10X1.5X16-MM)	2
8T4223	33 WASHER-HARD (13.5X25.5X3-MM THK)	12
9C5344	34 SPACER (10.5X20X18-MM THK)	8
9X8256	35 WASHER (6.6X12X2-MM THK)	10
3322726	36 FILM-STRIPE (RED, WHITE)(40-CM EACH)
3322726	36A FILM-STRIPE (RED, WHITE)(25-CM EACH)
3322726	36B FILM-STRIPE (RED, WHITE)(20-CM EACH)
