449-0387 CONVERSION GP-ROADINGAN ATTACHMENT

Group No: 449-0387
Part NumberPart NameQty
3S20931 STRAP-CABLE5
25600422 LAMP GP-REGISTRATION PLATE (12-VOLT)1
25838493 PLATE-IDENTIFICATION (ENGLISH, GERMAN, ITALIAN)1
27676954 MOUNTING GP-LIGHTING2
27784225 PLATE-INFORMATION (NO. 15)1
29577946 LIGHTING GP-WARNING BEACON (12-VOLT)2
9W3326LAMP (12-VOLT, 21-WATT)(MINIATURE)1
29583457 MIRROR1
31316478 BRACKET AS1
31316489 SUPPORT AS1
318025310 PLATE1
453883111 PLATE2
485392312 PLATE AS2
8T3490NUT-WELD (M10X1.5-THD)1
4842563PLATE1
129317813 LOCKNUT (M6X1-THD)2
131353914 SCREW-FLAT HEAD (M8X1.25X30-MM)2
329335615 NUT (M12X1.75-THD)5
344567416 NUT (M8X1.25-THD)2
5C955317 BOLT (M6X1X16-MM)2
5P411618 WASHER-HARD (8.8X20.5X2-MM THK)2
6V735719 BOLT (M6X1X25-MM)2
6V967320 SCREW-MACHINE (M5X0.8X12-MM)2
8T413921 BOLT (M12X1.75X30-MM)4
8T417922 BOLT (M12X1.75X20-MM)4
8T422323 WASHER-HARD (13.5X25.5X3-MM THK)12
9X825624 WASHER (6.6X12X2-MM THK)10
332272625 FILM-STRIPE (RED, WHITE)(40-CM EACH)
332272625A FILM-STRIPE (RED, WHITE)(20-CM EACH)
332272625B FILM-STRIPE (RED, WHITE)(40-CM EACH)
8T412126 WASHER-HARD (11X21X2.5-MM THK)4
130530027 CLIP2
8T419128 BOLT (M10X1.5X16-MM)2
7K118129 STRAP-CABLE5
7X253530 BOLT (M6X1X60-MM)4
8T418331 BOLT (M12X1.75X40-MM)1
552692133 SUPPORT-REAR2
9C534434 SPACER (10.5X20X18-MM THK)8
493412635 HARNESS AS-CONTROL1
9X3401PIN-CONNECTOR (16-GA TO 18-GA)2
1261767PIN-CONNECTOR (14-GA TO 16-GA)2
1552270KIT-CONNECTING PLUG (2-PIN)1
1028802KIT-RECEPTACLE (2-PIN)1
1945226TERMINAL AS (16-GA)2
1945227TERMINAL AS (14-GA)2
495147536 PLATE1
