Assembly
100%

449-0368 COVER GP-REARPART OF 456-7935 COVER GP-REAR

Group No: 449-0368
Part NumberPart NameQty
29640901 HINGE AS4
30531692 PAWL3
32606103 LATCH AS3
1H3244LOCKWASHER4
0951207NUT (M12X1.75-THD)2
3260612WASHER-TAB2
3445673NUT (M6X1-THD)4
45236754 COVER AS1
7T1099LINK4
8T3490NUT-WELD (M10X1.5-THD)4
8T3612NUT-WELD (M8X1.25-THD)18
6V9632NUT-WELD (M6X1-THD)3
45388305 PLATE AS1
7T1099LINK4
8T3612NUT-WELD (M8X1.25-THD)3
45897616 COVER AS1
8T3612NUT-WELD (M8X1.25-THD)5
46029467 COVER AS1
46029488 DOOR AS1
8T3612NUT-WELD (M8X1.25-THD)4
46253029 COVER GP-REAR1
463375110 PLATE2
480060611 BRACKET AS (RH)1
8T3612NUT-WELD (M8X1.25-THD)3
480060712 BRACKET AS (LH)1
7T1099LINK3
8T3612NUT-WELD (M8X1.25-THD)3
099364913 BOLT (M8X1.25X40-MM)2
171945514 SCREW (8X1.25X16-MM)4
198389915 SCREW-BUTTON HEAD (M8X1.25X20-MM)8
3T085216 LOCKNUT (M8X1.25-THD)2
461883017 SPRING AS-GAS (DOOR ACCESS)1
5P411618 WASHER-HARD (8.8X20.5X2-MM THK)25
7Y739419 SCREW-BUTTON HEAD (M8X1.25X25-MM)10
8T038920 LOCKNUT (M10X1.5-THD)6
8T412121 WASHER-HARD (11X21X2.5-MM THK)20
8T418622 BOLT (M10X1.5X40-MM)8
8T418923 BOLT (M8X1.25X20-MM)7
8T419624 BOLT (M10X1.5X35-MM)6
8T422425 WASHER-HARD (8.8X16X2-MM THK)8
9G267326 GROMMET2
9X261627 SCREW-SOCKET (M8X1.25X16-MM)4
9X825628 WASHER (6.6X12X2-MM THK)12
307868629 PLUG-BUTTON1
8T399130 SCREW-BUTTON HEAD (M6X1X20-MM)3
