Assembly
100%

463-3736 DOOR GP-ACCESSPART OF 456-7935 COVER GP-REAR

Group No: 463-3736
Part NumberPart NameQty
10877561 ROD1
23931732 HINGE2
30531693 PAWL1
30665194 PLATE1
32606105 LATCH AS1
1H3244LOCKWASHER4
0951207NUT (M12X1.75-THD)2
3260612WASHER-TAB2
3445673NUT (M6X1-THD)4
45228436 PLATE-SUPPORT1
46029307 PLATE1
46050998 PLATE2
46337389 COVER AS1
463375210 DOOR GP-ACCESS (HOOD SIDE)1
468966311 PLATE1
468966412 PLATE1
468966513 PLATE1
470649414 PLATE1
474069115 COVER1
114048917 BOLT (M5X0.8X75-MM)4
6V845418 SCREW-HEX SOCKET (M8X1.25X16-MM)4
344567419 NUT (M8X1.25-THD)6
3B461720 PIN-COTTER1
4B427421 WASHER (5.5X13X1.2-MM THK)4
5P411623 WASHER-HARD (8.8X20.5X2-MM THK)4
7X262124 BOLT (M10X1.5X12-MM)4
7X772925 WASHER (11X25X3-MM THK)12
131353926 SCREW-FLAT HEAD (M8X1.25X30-MM)4
8T038927 LOCKNUT (M10X1.5-THD)4
8T418628 BOLT (M10X1.5X40-MM)4
8T422329 WASHER-HARD (13.5X25.5X3-MM THK)1
8T422430 WASHER-HARD (8.8X16X2-MM THK)24
8T490831 BOLT (M8X1.25X25-MM)20
8T754732 BOLT (M8X1.25X30-MM)2
258464834 SEAL (7.7-CM EACH)
258464834A SEAL (13.4-CM)
258464834B SEAL (14.3-CM)
256766935 PLATE4
291646536 SEAL (15-CM)
