Assembly
100%

463-3752 DOOR GP-ACCESSPART OF 463-3736 DOOR GP-ACCESS

Group No: 463-3752
Part NumberPart NameQty
49341211 LATCH AS8
1983899SCREW-BUTTON HEAD (M8X1.25X20-MM)8
26951382 WASHER (13X24X3-MM THK)8
29640903 HINGE AS8
46337534 DOOR GP-ACCESS (FRONT, RH)1
46337565 DOOR GP-ACCESS (REAR, RH)1
46337586 DOOR GP-ACCESS (FRONT, LH)1
46337617 DOOR GP-ACCESS (REAR, LH)1
13135398 SCREW-FLAT HEAD (M8X1.25X30-MM)8
44707839 ROD GP (ADJUSTABLE)2
3T085210 LOCKNUT (M8X1.25-THD)16
7X253611 BOLT (M8X1.25X14-MM)8
7Y739412 SCREW-BUTTON HEAD (M8X1.25X25-MM)16
8T422413 WASHER-HARD (8.8X16X2-MM THK)24
522721214 PLATE12
