System And Components
372-8882 MODULE GP-COOLINGS/N P271-UP
Group No: 372-8882
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V7238 | 1 VALVE-SHUTOFF (COOLANT DRAIN) | 1 | |
| 2330060 | 2 FILM-IDENTIFICATION (LIFT EYE LOCATION) | 2 | |
| 2977987 | 3 ELBOW | 1 | |
| 3570003 | 4 PIN | 16 | |
| 3570004 | 5 SEAL-AIR | 1 | |
| 3570005 | 6 SEAL-AIR | 2 | |
| 3628702 | 7 BRACKET AS | 4 | |
| 3628703 | 8 MOUNT AS | 4 | |
| 3628704 | 9 BRACKET | 4 | |
| 3728883 | 10 CORE AS-RADIATOR (HYDRAULIC PUMP OIL) | 1 | |
| 3728885 | 11 CORE AS-OIL COOLER (HYDRAULIC PUMP OIL) | 1 | |
| 3728886 | 12 BRACKET AS | 1 | |
| 3728887 | 13 BRACKET AS | 1 | |
| 3728888 | 14 BRACKET AS | 1 | |
| 3728889 | 15 BRACKET AS | 1 | |
| 3728892 | 16 BRACKET AS | 1 | |
| 3728893 | 17 SEAL-AIR | 1 | |
| 3728894 | 18 SEAL-AIR | 1 | |
| 3764768 | 19 PLATE AS | 1 | |
| 3764769 | 20 PLATE AS | 1 | |
| 3764770 | 21 BRACKET AS | 2 | |
| 3852618 | 22 CORE AS-AFTERCOOLER (AIR COOLING) | 1 | |
| 1757141 | 23 NUT-HEX FLANGE (M10X1.5-THD) | 8 | |
| 5P1076 | 24 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 6V5048 | 25 SEAL-O-RING | 1 | |
| 6V6609 | 26 SEAL-O-RING | 1 | |
| 7X2546 | 27 BOLT (M10X1.5X180-MM) | 8 | |
| 7X7729 | 28 WASHER (11X25X3-MM THK) | 66 | |
| 8T4136 | 29 BOLT (M10X1.5X25-MM) | 18 | |
| 8T4137 | 30 BOLT (M10X1.5X20-MM) | 24 | |
| 8T4139 | 31 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4179 | 32 BOLT (M12X1.75X20-MM) | 8 | |
| 8T4186 | 33 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4226 | 34 WASHER-PLATED (10.5X45X3-MM THK) | 4 |
