323-7218 LINES GP-BOOM CYLINDERS/N P271-UP

Group No: 323-7218

Part Number	Part Name	Qty
9F2167	1 SCREW-PURGE (3/8-24X1.164-IN)	1
1021174	2 GUARD (20-CM EACH)
1287591	3 SUPPORT AS	1
1708553	4 BOLT-SOCKET HEAD (M12X1.75X40-MM)	4
4348214	5 SENSOR GP-PRESSURE (BOOM LOWERING CONTROL)	1
2927367	6 FLANGE	1
3100147	7 VALVE GP-LOAD CONTROL (BOOM CYLINDER)	1
3199717	8 TUBE AS	1
3199719	9 SUPPORT AS	1
3199721	10 SUPPORT AS	1
3199727	11 HOSE AS	1
3199798	12 SUPPORT AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
3258787	13 TUBE AS	1
3302314	14 TUBE AS	1
3543813	15 HOSE AS	1
3543819	16 HOSE AS	1
1017397	17 BOLT-SOCKET HEAD (M12X1.75X50-MM)	4
1083819	18 BOLT-SOCKET HEAD (M12X1.75X70-MM)	4
1087550	19 CLIP	2
1132004	20 BOLT-SOCKET HEAD (M12X1.75X45-MM)	4
1488322	21 CONNECTOR AS	1
2M9780	SEAL-O-RING	1
6V8640	CONNECTOR	1
6V9746	SEAL-O-RING	1
1488336	22 CONNECTOR AS	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V8636	CONNECTOR	1
1488353	23 ELBOW AS	1
3J1907	SEAL-O-RING	1
6V8397	SEAL-O-RING	1
6V9001	ELBOW	1
1P3703	24 SEAL-RECTANGULAR	6
1P3704	25 SEAL-RECTANGULAR	6
1P5767	26 FLANGE-HALF	8
5P0047	27 COVER	4
6V0400	28 FLANGE-HALF	8
6V1324	29 GROMMET	1
7G3413	30 CLIP (SLOT)	1
7G3414	31 CLIP (TAB)	1
8T4121	32 WASHER-HARD (11X21X2.5-MM THK)	2
8T4136	33 BOLT (M10X1.5X25-MM)	2
8T4139	34 BOLT (M12X1.75X30-MM)	14
8T4184	35 BOLT (M12X1.75X45-MM)	18
8T4194	36 BOLT (M12X1.75X50-MM)	16
8T4223	37 WASHER-HARD (13.5X25.5X3-MM THK)	48
1092013	38 GUARD (8-CM)
5P1076	39 WASHER-HARD (13.5X30X4-MM THK)	2
8T4648	40 BOLT (M12X1.75X70-MM)	2
2344492	41 SUPPORT	1
