Assembly
100%

526-7046 LINES GP-BOOM CYLINDER -BOOMS/N P271-UP

Group No: 526-7046
Part NumberPart NameQty
9F21671 SCREW-PURGE (3/8-24X1.164-IN)1
10211742 GUARD (10-CM EACH)
17085533 BOLT-SOCKET HEAD (M12X1.75X40-MM)4
23444924 SUPPORT1
29273675 FLANGE1
31997196 SUPPORT AS1
33023147 TUBE AS1
11320048 BOLT-SOCKET HEAD (M12X1.75X45-MM)4
1P37039 SEAL-RECTANGULAR2
1P370410 SEAL-RECTANGULAR2
1P576711 FLANGE-HALF4
5P004812 COVER2
5P107613 WASHER-HARD (13.5X30X4-MM THK)2
6V132414 GROMMET1
6V983215 CAP (ORFS)1
7G341316 CLIP (SLOT)1
7G341417 CLIP (TAB)1
8T413918 BOLT (M12X1.75X30-MM)2
8T418419 BOLT (M12X1.75X45-MM)2
8T419420 BOLT (M12X1.75X50-MM)8
8T422321 WASHER-HARD (13.5X25.5X3-MM THK)12
8T464822 BOLT (M12X1.75X70-MM)2
