System And Components
393-4939 LINES GP-BOOM CYLINDER -BOOM LOWERING CONTROL, RHS/N TDY1-UP
Group No: 393-4939 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 1 | |
| 0931295 | 2 CLAMP | 1 | |
| 3923943 | 3 SUPPORT AS | 1 | |
| 3965356 | 4 SUPPORT AS | 1 | |
| 3965362 | 5 TUBE AS | 1 | |
| 3965363 | 6 TUBE AS | 1 | |
| 4159862 | 7 VALVE GP-PILOT | 1 | |
| 1488336 | 8 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488371 | 9 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1488378 | 10 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488382 | 11 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T0404 | ELBOW | 1 | |
| 1488433 | 12 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1645567 | 13 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2802747 | 14 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 4 | |
| 4J5267 | 15 SEAL-O-RING | 2 | |
| 7J9108 | 16 SEAL-O-RING | 2 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4182 | 18 BOLT (M10X1.5X45-MM) | 4 | |
| 8T4194 | 19 BOLT (M12X1.75X50-MM) | 1 | |
| 8T4196 | 20 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
