System And Components
513-6908 MANIFOLD GP-EXHAUSTS/N D8T1-UP
Group No: 513-6908
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1068916 | 1 BOLT (M6X1X16-MM) | 2 | |
| 1243815 | 2 BOLT (M8X1.25X16-MM) | 4 | |
| 3574390 | 3 CONNECTOR AS | 1 | |
| 8T7489 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2287101 | SEAL-O-RING | 1 | |
| 1978418 | 4 GASKET | 1 | |
| 1978419 | 5 GASKET | 1 | |
| 1984765 | 6 WASHER-HARD (8.8X20X8-MM THK) | 1 | |
| 2321295 | 7 PLUG | 2 | |
| 2388292 | 8 BOLT-FLANGE HEAD | 12 | |
| 2780017 | 9 GASKET | 2 | |
| 2867851 | 10 SPACER | 12 | |
| 3161164 | 11 WASHER | 2 | |
| 3499387 | 12 MANIFOLD | 1 | |
| 3570617 | 13 GASKET | 1 | |
| 3717601 | 14 GASKET | 2 | |
| 4322374 | 15 LINE AS | 1 | |
| 4322376 | 16 LINE AS | 1 | |
| 4578672 | 17 BOLT (M10X1X22-MM) | 1 | |
| 4836998 | 18 HOSE & TUBE AS | 1 | |
| 1232933 | CLIP | 2 | |
| 2287089 | SEAL-O-RING | 1 | |
| 4836999 | 19 HOSE & TUBE AS | 1 | |
| 8L2777 | SEAL-O-RING | 2 | |
| 5014145 | 20 BRACKET AS | 1 | |
| 6I0217 | 21 BOLT (M8X1.25X20-MM) | 5 | |
| 6I0254 | 22 BOLT (M8X1.25X30-MM) | 2 | |
| 6I0260 | 23 BOLT (M8X1.25X25-MM) | 1 |
