System And Components
439-2523 LINES GP-AIRS/N NLG1-UP; PRG1-UP
Group No: 439-2523 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2287103 | 1 SEAL-O-RING | 1 | |
| 2566453 | 2 SENSOR-TEMPERATURE (2-PIN)(INLET AIR) | 1 | |
| 2566454 | 3 SENSOR-TEMPERATURE (2-PIN)(AMBIENT AIR) | 1 | |
| 3203063 | 4 SENSOR GP-PRESSURE (ATMOSPHERIC AIR) | 1 | |
| 3514015 | 5 HOSE-AIR | 1 | |
| 3514016 | 6 PIPE AS | 1 | |
| 4392546 | 7 HOSE-AIR | 1 | |
| 1440367 | 8 CLAMP-HOSE | 2 | |
| 2287100 | 9 SEAL-O-RING | 1 | |
| 2385080 | 10 SEAL-O-RING | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4985 | 13 CLAMP-HOSE | 2 |
