System And Components
353-0782 LINES GP-BLADE CYL & VALVE -MEDIUM PRESSURES/N NLG1-UP; PRG1-UP
Group No: 353-0782 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931295 | 1 CLAMP | 2 | |
| 1391762 | 2 HOSE AS | 2 | |
| 1391765 | 3 HOSE AS | 2 | |
| 1797874 | 4 TUBE AS | 1 | |
| 1797875 | 5 TUBE AS | 1 | |
| 2967178 | 6 HOSE AS | 1 | |
| 3075072 | 7 SUPPORT | 1 | |
| 4842318 | 8 HOSE AS | 1 | |
| 3099972 | 9 VALVE GP-CONTROL (BLADE, MEDIUM PRESSURE, RELIEF) | 1 | |
| 1017401 | 10 BOLT-SOCKET HEAD (M10X1.5X20-MM) | 4 | |
| 1488341 | 11 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488407 | 12 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1503037 | 13 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T2530 | ELBOW | 1 | |
| 1504048 | 14 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8722 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 7J9108 | 15 SEAL-O-RING | 8 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4194 | 17 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4196 | 18 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 7K1181 | 20 STRAP-CABLE | 1 | |
| 1488342 | 21 CONNECTOR AS | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 3K0360 | SEAL-O-RING | 1 |
