System And Components
353-0770 LINES GP-FRONT -MED PRESS, LOAD SENSING VALVES/N NLG1-UP; PRG1-UP
Group No: 353-0770 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0931295 | 1 CLAMP | 1 | |
| 2895547 | 2 PLATE | 1 | |
| 3075072 | 3 SUPPORT | 1 | |
| 3100165 | 4 VALVE GP-CONTROL (MEDIUM PRESSURE, PUMP RELIEF) | 1 | |
| 3259054 | 5 HOSE AS | 2 | |
| 3569193 | 6 TUBE AS | 1 | |
| 3569194 | 7 HOSE AS | 1 | |
| 3661007 | 8 HOSE AS | 1 | |
| 3661084 | 9 TUBE AS | 1 | |
| 1017401 | 10 BOLT-SOCKET HEAD (M10X1.5X20-MM) | 4 | |
| 1488346 | 11 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 1488364 | 12 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488407 | 13 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 6V8398 | 14 SEAL-O-RING | 4 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4184 | 16 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4196 | 17 BOLT (M10X1.5X35-MM) | 6 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 1 |
