System And Components
396-9452 GEAR GP-REARS/N RDP646-UP
Group No: 396-9452
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P8244 | 1 WASHER-HARD (12X22.5X2.5-MM THK) | 6 | |
| 1W4746 | 2 RETAINER-GEAR | 2 | |
| 2W0493 | 3 GEAR AS-IDLER (74-TEETH) | 1 | |
| 1W4738 | BUSHING | 1 | |
| 2W0494 | 4 GEAR AS-IDLER (64-TEETH) | 1 | |
| 1W4738 | BUSHING | 1 | |
| 2W0496 | 5 GEAR AS-CRANKSHAFT (68-TEETH) | 1 | |
| 4N0684 | DOWEL | 1 | |
| 7N8374 | 6 COVER-PUMP | 1 | |
| 5P8245 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5P8247 | 8 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 1753721 | 9 COVER | 1 | |
| 2878358 | 10 GEAR AS-PUMP DRIVE (64-TEETH) | 1 | |
| 4F6024 | PIN | 1 | |
| 1878230 | 11 ADAPTER AS | 1 | |
| 1608184 | BUSHING | 1 | |
| 3949956 | 12 ADAPTER AS-PUMP | 1 | |
| 1608184 | BUSHING | 1 | |
| 3969451 | 13 GEAR AS (15-TEETH) | 1 | |
| 4F6024 | PIN | 1 | |
| 9X7371 | 14 SEAL-O-RING | 1 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 1 | |
| 0S1619 | 16 BOLT (3/8-16X3-IN) | 1 | |
| 0T0768 | 17 BOLT (7/16-14X1.75-IN) | 6 | |
| 1A1460 | 18 BOLT (1/2-13X2-IN) | 6 | |
| 1A2029 | 19 BOLT (3/8-16X1.125-IN) | 6 | |
| 2348937 | 20 SEAL-INTEGRAL | 1 | |
| 2J1712 | 21 SCREW-SOCKET (1/2-13-THD) | 2 | |
| 2P2772 | 22 COVER | 1 | |
| 4B4043 | 23 BOLT (5/8-11X1.375-IN) | 2 | |
| 4M0189 | 24 SEAL-O-RING | 2 | |
| 4N1230 | 25 SEAL-O-RING | 2 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 |
