System And Components
368-8298 LINES GP-ENGINE OIL DRAINS/N PA91-UP
Group No: 368-8298
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8B3410 | 1 GASKET | 1 | |
| 8C6524 | 2 ADAPTER | 1 | |
| 2228210 | 3 CONNECTOR | 1 | |
| 3109508 | 4 ADAPTER | 1 | |
| 3688331 | 5 PLATE | 1 | |
| 3688332 | 6 HOSE AS | 1 | |
| 1108827 | 7 FITTING (QUICK DISCONNECT, MALE) | 1 | |
| 1358575 | 8 BOLT AS | 2 | |
| 1455181 | 9 SPACER (13.5X25X12-MM THK) | 1 | |
| 2V2043 | 10 NUT-BULKHEAD (1-5/8-12-THD) | 1 | |
| 3196216 | 11 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 5P7466 | 12 CLIP (SLOT) | 2 | |
| 5P7467 | 13 CLIP (TAB) | 2 | |
| 5P8112 | 14 GROMMET | 2 | |
| 6V3830 | 15 SEAL-O-RING | 1 | |
| 8L2786 | 16 SEAL-O-RING | 2 | |
| 8T0119 | 17 ELBOW | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4195 | 20 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4835 | 22 BOLT (1/2-13X2-IN) | 1 | |
| 8T8920 | 23 BOLT (1/2-13X3.25-IN) | 1 | |
| 9S4185 | 24 PLUG (3/4-16-THD) | 1 |
