System And Components
443-2100 MODULE GP-COOLINGS/N PA91-UP
Group No: 443-2100
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2214872 | 1 HOSE | 2 | |
| 2330060 | 2 FILM-IDENTIFICATION (LIFT EYE LOCATION) | 2 | |
| 3355462 | 3 PIN | 32 | |
| 3364433 | 4 PIN | 8 | |
| 3607693 | 5 CORE AS-AFTERCOOLER | 1 | |
| 3607703 | 6 SEAL-AIR | 1 | |
| 3607704 | 7 SEAL-AIR | 1 | |
| 3607705 | 8 SEAL-AIR | 5 | |
| 3607706 | 9 SEAL-AIR | 1 | |
| 3634152 | 10 BLOCK | 4 | |
| 3640696 | 11 PLATE | 1 | |
| 3688877 | 12 BRACKET AS | 2 | |
| 3752749 | 14 PLATE AS | 2 | |
| 3782891 | 15 PLATE | 1 | |
| 3817191 | 16 FRAME AS (TOP) | 1 | |
| 3817192 | 17 FRAME AS-BOTTOM | 1 | |
| 3817194 | 18 FRAME AS (LH) | 1 | |
| 3817195 | 19 FRAME AS (MIDDLE) | 2 | |
| 3817196 | 20 FRAME AS (TOP) | 1 | |
| 3817197 | 21 FRAME AS-BOTTOM | 1 | |
| 3817198 | 22 BRACKET AS-FRAME | 4 | |
| 3817200 | 23 PLATE | 3 | |
| 4432105 | 24 FRAME AS | 1 | |
| 3841352 | 25 COOLER AS-FUEL | 1 | |
| 3178141 | MOUNT | 4 | |
| 3953755 | 26 CORE AS-RADIATOR | 2 | |
| 4231745 | 27 FRAME AS | 1 | |
| 4432101 | 28 CORE AS-OIL COOLER | 2 | |
| 4432102 | 29 FRAME AS (RH) | 1 | |
| 4432103 | 30 GUSSET | 4 | |
| 4432104 | 31 BLOCK | 4 | |
| 1440367 | 32 CLAMP-HOSE | 8 | |
| 1891943 | 33 LOCKNUT (M10X1.5-THD) | 20 | |
| 5P1076 | 34 WASHER-HARD (13.5X30X4-MM THK) | 51 | |
| 6E5293 | 35 BOLT (M10X1.5X210-MM) | 20 | |
| 7X0515 | 36 WASHER-HARD (17X35X5-MM THK) | 20 | |
| 7X0579 | 37 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 7X7729 | 38 WASHER (11X25X3-MM THK) | 98 | |
| 8T4136 | 39 BOLT (M10X1.5X25-MM) | 22 | |
| 8T4137 | 40 BOLT (M10X1.5X20-MM) | 20 | |
| 8T4139 | 41 BOLT (M12X1.75X30-MM) | 47 | |
| 8T4140 | 42 BOLT (M16X2X60-MM) | 8 | |
| 8T4183 | 43 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4195 | 44 BOLT (M10X1.5X30-MM) | 16 | |
| 8T4223 | 45 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4908 | 46 BOLT (M8X1.25X25-MM) | 4 | |
| 1729966 | 47 BOLT (M12X1.75X65-MM) | 8 | |
| 8T7338 | 48 BOLT (M16X2X45-MM) | 12 |
