System And Components
368-8290 LINES GP-AIRS/N PA91-UP
Group No: 368-8290
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4724 | 1 CLAMP-HOSE | 1 | |
| 4W9160 | 2 CLAMP-V BAND | 1 | |
| 6V3582 | 3 CLAMP-HOSE | 1 | |
| 1318829 | 4 VALVE-DUST (AIR CLEANER) | 1 | |
| 1380167 | 5 GROMMET | 1 | |
| 2566453 | 6 SENSOR-TEMPERATURE (2-PIN)(AIR INLET) | 1 | |
| 3203063 | 7 SENSOR GP-PRESSURE (AIR INLET) | 1 | |
| 3688334 | 8 HOSE-AIR | 1 | |
| 3688335 | 9 HOSE-AIR | 1 | |
| 3688341 | 10 PLATE | 1 | |
| 3851285 | 11 HOSE | 1 | |
| 3963277 | 12 ELBOW AS | 1 | |
| 3885464 | ELBOW-AIR | 1 | |
| 2P1692 | SEAL-O-RING | 1 | |
| 4549795 | 13 PIPE AS | 1 | |
| 4549800 | 14 PIPE | 1 | |
| 1358575 | 15 BOLT AS | 5 | |
| 3K0360 | 16 SEAL-O-RING | 1 | |
| 6V9028 | 17 SEAL-O-RING | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4988 | 20 CLAMP-HOSE | 3 | |
| 8T4990 | 21 CLAMP-HOSE | 1 |
