438-1850 LINES GP-PILOTS/N PA91-UP

Group No: 438-1850
Part NumberPart NameQty
4I95211 BAND-MARKER (RED, L1)2
4I95222 BAND-MARKER (YELLOW, L2)2
4I95243 BAND-MARKER (BROWN, L4)2
4I95254 BAND-MARKER (ORANGE, R1)2
4I95265 BAND-MARKER (WHITE, R2)2
4I95286 BAND-MARKER (PURPLE, R4)2
46649017 GROMMET2
47116648 BRACKET2
47116669 HOSE AS1
471166710 HOSE AS1
471166811 HOSE AS2
471166912 HOSE AS2
148844413 TEE AS-SWIVEL1
6V8398SEAL-O-RING2
6V9837TEE-SWIVEL1
148845714 UNION AS (STRAIGHT)2
6V8398SEAL-O-RING2
6V8995UNION (STRAIGHT)1
149545215 UNION AS (STRAIGHT)4
6V8397SEAL-O-RING2
6V8994UNION (STRAIGHT)1
6V916816 NUT (11/16-16-THD)4
6V916917 NUT (13/16-16-THD)2
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)3
8T686819 BOLT (M12X1.75X80-MM)3
9R388420 SPACER (13X20X45-MM THK)3
102117421 GUARD (124-CM)
